Fiberglass-Resin Composite Vessels: Light, Strong & Green Shipbuilding Innovation
 Dec 15, 2025|View:376

As the global shipping industry accelerates its transition to green and low-carbon operations, glass fiber-reinforced resin matrix composites (hereafter referred to as "fiberglass-resin") are emerging as a new core material in shipbuilding, thanks to their "lightweight, high-strength, and corrosion-resistant" properties. Recently, a domestic shipbuilding enterprise delivered its first batch of fiberglass-resin fishing vessels and leisure boats for mass deployment, marking a breakthrough in the large-scale application of this composite material in civilian shipbuilding.


Performance Revolution: 70% Lighter Than Steel, Twice the Lifespan of Traditional Vessels

Fiberglass-resin hulls use a "glass fiber + high-performance resin" composite structure, with a density just 1/4 that of steel. Vessels of the same tonnage see a 30%-50% weight reduction, directly cutting fuel consumption by 15%-20%. For a 100-ton offshore fishing vessel, this translates to annual fuel cost savings of 20,000-40,000 RMB, with an investment payback period of only 3-5 years.Its mechanical performance is equally impressive: tensile strength reaches 300-1000 MPa, and impact resistance outperforms steel—hulls remain intact even in Level 8 wind and waves. Its chemical inertness provides strong resistance to seawater corrosion and marine biological borers, with a service life of 15-20 years (3x that of wooden fishing boats and 2x that of ordinary steel vessels), reducing lifecycle maintenance costs by over 60%.

Process Upgrade: Vacuum Infusion + Recycled Materials for "Green Shipbuilding"

These vessels adopt the vacuum infusion molding process, which ensures uniform resin impregnation of fiber layers, boosting material utilization to 95% and cutting volatile organic compound (VOC) emissions by 90%—aligning with eco-friendly production standards. Meanwhile, some models innovatively use recycled fiberglass-resin materials: regenerated glass fibers, separated via pyrolysis, retain over 90% of their performance; when mixed with virgin materials, they reduce single-vessel carbon emissions by 70%, enabling a "manufacture-recycle-reuse" circular loop.

Scenario Adaptability: Reshaping the Marine Equipment Landscape from Fishing to Tourism

Currently, fiberglass-resin vessels have been deployed across diverse scenarios:
  • Fishing: Sea trials of 80-ton trawlers show 18% lower fuel consumption than steel vessels, with no corrosion damage after 2 years—garnering over 90% approval from fishermen;

  • Leisure & Tourism: Fiberglass-resin sea fishing boats feature low vibration and noise (≤52dB inside cabins); combined with lightweight design, they offer 40% better sailing stability, becoming a new favorite for coastal tourism;

  • Special Operations: Shallow-draft mudflat workboats and impact-resistant law enforcement vessels, tailored with customized structural designs, adapt to complex water area needs.

"Fiberglass-resin materials are rewriting the 'weight-performance' equation in shipbuilding," noted the enterprise's technical director. Next, the company will advance the integration of large-tow glass fibers and bio-based resins, aiming to cut material costs by another 20% and help more green vessels sail into global markets.
